Rivet
dia.
(mm) |
Hole
Size
(mm) |
Rivet
No. |
Grip range
(mm) |
Rivet length |
Head dia. |
Head height
(mm) |
Strength |
Dome h.
(mm) |
CSK h.
(mm) |
Dome h.
(mm) |
CSK h.
(mm) |
Tensile
N
(kgf.) |
Shear
N
(kgf.) |
| D |
G |
L |
H |
E |
| 2.4 |
2.5 |
32 |
1.0 - 3.2 |
5.6 |
. |
4.8 |
. |
0.7 |
980
(100) |
880
(90) |
| 34 |
3.2 - 6.4 |
8.8 |
. |
| 3.2 |
3.3 |
41 |
1.0 - 1.6 |
4.7 |
. |
6.4 |
5.6
(6.4) |
0.9 |
1960
(200) |
1470
(150) |
| 42 |
1.6 - 3.2 |
6.3 |
6.7 |
| 43 |
3.2 - 4.8 |
7.9 |
8.3 |
| 44 |
4.8 - 6.4 |
9.5 |
9.9 |
| 45 |
6.4 - 8.0 |
11.1 |
. |
| 46 |
8.0 - 9.6 |
12.7 |
. |
| 48 |
9.6 -12.8 |
15.9 |
. |
| 4.0 |
4.1 |
52 |
1.2 - 3.2 |
6.8 |
. |
8.0 |
7.2
(8.0) |
1.1 |
2740
(280) |
1960
(200) |
| 54 |
3.2 - 6.4 |
10.0 |
10.2 |
| 56 |
6.4 - 9.6 |
13.2 |
13.5 |
| 58 |
9.6 -12.8 |
16.4 |
. |
| 4.8 |
4.9 |
62 |
1.6 - 3.2 |
7.7 |
. |
9.6 |
8.9
(9.6) |
1.3 |
3530
(360) |
3040
(310) |
| 64 |
3.2 - 6.4 |
10.9 |
11.2 |
| 66 |
6.4 - 9.6 |
14.1 |
14.5 |
| 68 |
9.6 -12.8 |
17.3 |
. |
| 610 |
12.8-16.0 |
20.5 |
. |
| 6.4 |
6.5 |
84 |
3.2 - 6.4 |
12.0 |
. |
12.8 |
. |
2.0 |
7640
(780) |
5290
(540) |
| 86 |
6.4 - 9.6 |
15.0 |
| 88 |
9.6 -12.8 |
18.0 |
| 810 |
12.8-16.0 |
21.0 |
| 812 |
16.0-19.2 |
24.0 |
| 814 |
19.2-22.7 |
27.0 |
* Colored rivets are also available.
* Other size of CSK head rivets can also be provided upon request.
Rivet
dia.
(mm) |
Hole
Size
(mm) |
Rivet
No. |
Grip range
(mm) |
Rivet length
(mm) |
Head dia.
(mm) |
Head height
(mm) |
Strength |
| D |
G |
L |
H |
E |
Tensile
N
(kgf.) |
Shear
N
(kgf.) |
| 4.8 |
4.9 |
64 |
3.2 - 6.4 |
12.0 |
15.9 |
2.0 |
3920
(400) |
3140
(320) |
| 66 |
6.4 - 9.6 |
15.0 |
| 68 |
9.6 -12.8 |
18.0 |
| 610 |
12.8-16.0 |
21.0 |
| 612 |
16.0-19.2 |
24.0 |
|
