| Sprecification |
| Rivet Material |
Nylon 6 (94-V2) |
| Mandrel Material |
Polycarbonate (94-V2) |
| PartNo, Order Code |
CR aa - b - c
aa = Rivet dia.
b.= Length
c.= Color
iEx : CR32-1-1j
|
Colors & Code No, |
| Color |
Black |
White |
Gray |
Beige |
| Color No, |
-1 |
-2 |
-3 |
-4 |
Spec. Table |
| Part No. |
Holo Dia.
(mm) |
Thickness
(mm) |
Dia
(mm) |
Length
(mm) |
Head Dia.
(mm) |
Head Height
(mm) |
Shear
(kg) |
Tensile
(kg) |
| CR32-1 |
3.3 |
1.0 - 4.0 |
3.2 |
6.4 |
6.4 |
1.4 |
12 |
20 |
| CR32-2 |
4.0 - 7.0 |
9.6 |
| CR32-3 |
7.0 -10.0 |
12.7 |
| CR40-1 |
4.1 |
1.0 - 4.0 |
4.0 |
6.4 |
8.0 |
1.8 |
18 |
25 |
| CR40-2 |
4.0 - 7.0 |
9.6 |
| CR40-3 |
7.0 -10.0 |
12.7 |
| CR48-1 |
4.9 |
1.5 - 5.0 |
4.8 |
8.0 |
9.6 |
2.0 |
28 |
40 |
| CR48-2 |
5.0 - 8.0 |
11.2 |
| CR48-3 |
8.0 -11.0 |
14.4 |
CAUTIONS
Please refer to the strength data on the table below.
It shows the strength at destruction in the room temperature at 25 degrees.
As the temperature where the rivet is used goes up, the strength goes down.
The strength rapidly decline exceeding the point of 70 degrees.
In outdoor applications, specially exposed in the sun, the material is getting inferior by aging with the influence of UV rays.
For particulars please apply to us.
|
|
|
